Want to Work More Efficiently, Minimize Errors, and Reduce Production Costs in Façade Construction? Then a robust 3D CAD system is a must. But how do you choose the right software? Here are the five indispensable features your 3D CAD system must have to make a difference.
Why is a 3D CAD System Essential for Façade Builders?
Façade construction is complex. From designing façades with sheet metal to working with BIM, it demands precision and collaboration. While a 2D CAD system may suffice for simpler projects like windows and frames, a 3D CAD system is essential if you want to:
- Handle complex façade designs.
- Implement process automation.
- Comply with BIM requirements.
With the right software, you can optimize your processes, save time, and enhance the quality of your projects.
5 Essential Features for a 3D CAD System in Façade Construction
Not every 3D CAD system is suitable for façade construction. Pay attention to these five critical features when choosing the right software.
1. Production Integration: From Design to Realization
A 3D CAD system must seamlessly communicate with your production processes. This prevents duplicate work, reduces the risk of errors, and accelerates turnaround times. Choose software that offers automatic production control, allowing you to send your designs to production with the press of a button.
2. Seamless Integration with LogiKal
For many façade builders, LogiKal is the standard for cost estimation and production control. A 3D CAD system that integrates seamlessly with LogiKal ensures smooth data exchange. This improves efficiency and prevents the loss of critical information. Systems like HiCAD are a great example of software that supports this integration effortlessly.
3. Working with Point Clouds
More and more façade builders are using 3D laser scans to accurately map construction sites. This creates a point cloud, a detailed dataset that serves as the foundation for a precise 3D model. A good 3D CAD system enables you to convert point clouds directly into usable 3D designs. This eliminates measurement errors and ensures a faster project start.
4. Modules Specifically for Façade Construction
Façade construction is a niche market. Therefore, it’s crucial that your CAD software includes features specifically developed for this sector. For example, a module like Element Installation automates the design of façade cladding. With it, you can quickly and accurately generate grids, drill holes, and substructures without manual intermediate steps.
5. BIM Functionality: Collaboration in a Single Model
BIM (Building Information Modeling) is indispensable in the construction industry. It enables all stakeholders to collaborate within a single integrated 3D model. A robust 3D CAD system offers full BIM support, ensuring compliance with standards like the Basic Information Delivery Specification (ILS). This reduces errors, saves time, and improves communication within projects.
Bonus: Combine 2D and 3D Modeling
Want to work truly efficiently? Opt for software that lets you model in both 2D and 3D. Modern systems like HiCAD allow you to seamlessly switch between the two. Changes made in a 3D model are automatically reflected in the corresponding 2D drawings, and vice versa. This not only saves you time but also prevents errors in your designs.
Optimize Your Façade Construction Projects with 3D CAD Software
A powerful 3D CAD system is the key to efficiency, error-free processes, and reduced costs in façade construction. By investing in software with the right features, you can get more out of your projects and strengthen your position in a competitive market.
