HiCAD 2024 - Service Pack 2

HiCAD 2024 Service Pack 2

With HiCAD 2024 - Service Pack 2, the latest program version of our CAD software is now available. We have made every effort to optimise many functions for easier and faster use. We have summarised the highlights of the version for you here.

  • Expansion of automatic quick view
  • Optimisation of section views
  • New versions of external formats
  • Drag and drop without dialogue
  • Redesign of pipes and containers
  • Pipe book for pipe isometries and pipe plans
  • and much more.

    For more information and an overview of all innovations, check out our online help.

New features in operation and user interface
Service Pack 2 includes a graphical update for the Start centre. There are minor improvements in the ICN, including the exclusive display of position text. There are also new features in external tools such as the CATEditor or the Report Manager.

Innovations in drawing detailing
The highlight of Service Pack 2 is magnetism for labelling objects, such as label flags or shape and position tolerances. Bending points can be moved easily and accurately. Unfolding, among other things, preserves the dimensional changes made by the user during alignment.

Innovations in modelling
In Service Pack 2, the cam connection offers even more practical options for angle drilling. Positioning now takes the machining direction into account for all workpiece types. There are also new features in the formula editor.

Access the release notes of this latest version here
